5Kwh 10Kwh 48V 100AH 200AH Wall Mouted Lithium Battery Pack

48V 200Ah(10Kwh) Deep Cycle LiFePO4 Battery with BMS 6000 times deep cycle charge and discharge. Iron phosphate-lithium power battery. Higher energy density, smaller volumn for household. Support connected in parallel mode for expansion. Photovoltaic system: This battery pack is designed for household photovoltaic systems.

  • Model: VL-BOX1
  • Product specification: 51.2V200Ah
  • Battery Voltage: 51.2V
  • Battery Capacity: 200Ah
  • Cycle Life: >6000times
  • Communication interface: RS485、RS232、CAN(Optional)
  • Communication: SMA, Growatt, Voltronic Power, Solis, Solax, Sungrow, Sofar, Goodwe etc
  • Warranty:5 years for machinery warranty






Product Detail

Product Tags

48V 100Ah LiFePO4 Powerwall Lithium Ion Battery

Voltai’ Lifepo4 battery pack is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS. BMS with improted chips and MOS,with balancing function and dual protection, has a wide range of performance and application advantages compared with conventional battery.

White and Black matte coler, Brand new unique design, various size vaild, easy installation, panel customization service, support for parallel expansion for large capacity applications. Customize BMS with various protection and communication functions ensures the reliable battery performance and remote real-time monitoring of battery data.

Product Application:

Product Application

Product Features:

◆High-quality 51.2V LiFePO4 powerwall, safety, deep cycle and long lifespan

◆100Ah and 200Ah powerwall, support up to 15 modules in parallel

◆LCD monitor the energy storage power data and operating status

◆Air cooling to improve the reliability of the product

◆External main switch to reduce product power consumption and improve safety

◆Wall brackets, which can meet the installation and use of different place

◆BMS bulit inside, over-voltage, over-load, over-temperature protection, atc

◆Compatible, can be connected to different types of loads within the voltage range

Product Parameter:

Product Model

51.2V 100AH

51.2V 200AH

Rated capacity

5120WH

10240WH

Nominal Voltage

51.2V

51.2V

Nominal Capacity

100AH

200AH

Cell Type

LIFEPO4

LIFEPO4

Standard Charging Voltage

58.4V

58.4V

Max Charge Current

100AH

200AH

Discharge Cut-off Voltage

40V

40V

Max Discharge Current

100AH

200AH

Parallel Function

8pcs

8pcs

Depth of Discharge

>85%

>85%

Cycle Life

>6000cycles (0.5C)

>6000cycles (0.5C)

Charging Temperature Range

0~50

0~50

Discharging Temperate Range

-20~60

-20~60

Color

(White and Black)

(White and Black)

Dimension

L630*W400*H217.5(MM)

L685*W400*H287(MM)

Weight

Around 45KG

Around 86KG

Installation Method

Wall Mounted

Wall Mounted

Communication Interface

CAN, RS485

CAN, RS485

Warranty

5 years

5 years

Package

Wooden Case

Wooden Case

 Battery Testing Curve:

Battery-Curve3

Product Size:

  • 51.2V 100AH—-General View
  • 51.2v 100ah51.2V 200AH—General View
  • 51.2 200Ah
  • Solar system Connection:
  • SOLAR SYSTEM CONNECTION
  • Accessories Details:
  • Solar Accessories1

All the related accessories are available. We can provide all you need.

Package Details:

powerwall package
