ESS Energy Storage System 48V 100Ah LiFePO4 Lithium ion Battery with 6000 Cycles Life

Battery Type: LiFePo4

Battery Voltage: 48V

Battery Capacity: 100Ah

Approx Dimension (mm):442*385*132mm
Approx Weight (Kg):29KG
Certificate:ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on

Product Detail

Product Tags

Compared with traditional batteries, Voltai’ high-voltage lithium battery energy storage system has a wide range of performance and application advantages. The leading lithium battery technology, BMS technology and system design ca-pabilities will bring excellent performance and reliability, while also providing the best solution for industrial. applications.

Key Features:

★Automotive Grade Cells-16 cell
configuration
★Integrated CAN bus RS485 BMS.
★LCD display shows battery
information.
★Pre-configured with optimal
parameters.
★No other LiFePO4 battery offers .
this functionality, longevity
and warranty at our price.
★Warranted for daily cycling.
★Optlonal Smart Heating Functlon
Can work -409C Degree

Application:
★Over charge detection function
★Over discharge detection function
★Over current detection function
★Temperature protection function
★Short circuit detection function
★Balance function
★Upper computer software monitor
★LCD Screen optional

Technical Parameters:

Specifications
JLS-LFP48100
Voltage
48 V
Nominal Capacity (40°C , 0.5C)
100 Ah
Weight (Approximate)
50Kg

Energy

Normal energy (40°C , 0.5C)
4800 Wh
Volumetric energy density
95Wh/L
Gravimetric energy density
96Wh/kg
Dimensions (W*D*H)
Width*Depth* Height
442mm*440mm*222.5mm

Standard Discharge 25°C

Max. constant current
50A
Cut-off voltage
42V

Standard charge 25℃

Charge Voltage
53.5V~54V
Max. constant current
50A
Recommended charging current and time
40A(0.4C) for 3 hours
Round trip efficiency(%)
>98%
Calendar life
25℃
>5 years
Cycle life (0.5C, 25℃)
60% DOD 4000 cycles

Operating temperature

Charging: 0℃~55℃
Discharging: -20℃~65℃
Storage temperature
Recommended range: -20℃~55℃

Cycle Life

48v 100ah

48V 100ah home battery storage system

48V 100ah home battery storage system

48V 100ah home battery storage system





Package and Shipment:
