Deep Cycle Lifepo4 24v 200ah Lithium Ion Battery 25.6v 200ah Storage Energy System
Main Features:
- 12V,24V, 48V LiFePO4 pack, safe and reliable
- Top brand cell such as CATL Cells cycles times: ≧3000
- 3 years warranty, 5 years life design.
- With intelligent BMS system to optimize the performance
- Built in 1.2A cell equalizer, can balance all cells in short time with cell difference as small as 0.05V.
- Max discharge current up to 200A, compatible with Solar system Excellent
- standby self-consumption as low as 4mA Wall amounted or horizontal design for option, easy installation.
- All around protection and unattended operation
- Optional for LCD display or communication (CAN/RS485/RS232)
- Automatically output cut off after 30days no charge and discharge to ensure security, also can cut off output by manual operation
|
MODEL
|
12V100AH
|
12V200AH
|
24V100AH
|
24V200AH
|
48V100AH
|
|
Battery Type
|
LiFePO4
|
||||
|
Normal Battery Voltage(Vdc)
|
12.8V
|
12.8V
|
25.6V
|
25.6V
|
51.2V
|
|
Normal Capacity(25℃，0.2C)（WH）
|
1280WH
|
2560WH
|
2560WH
|
5120WH
|
5120WH
|
|
Voltage window (Vdc)
|
11.2～14.6V
|
11.2～14.6V
|
22.4～29.2V
|
22.4～29.2V
|
44.8～58.4V
|
|
Folat Charge Voltage(Vdc)
|
13.8V
|
13.8V
|
27.6V
|
27.6V
|
55.2V
|
|
Max.continue discharge current（A）
|
100
|
150
|
100
|
150
|
100
|
|
Max.pulse discharge current（A）
|
200A 30Sec.
|
200A 30Sec.
|
200A 30Sec.
|
200A 30Sec.
|
200A 30Sec.
|
|
Max.continue charge current（A）
|
100
|
100
|
100
|
100
|
100
|
|
Case design
|
Horizontal design
|
Wall mounted or Horizontal design (Optional)
|
|||
|
Cycle life(+25℃ 0.2C）
|
≧3000 Cycles
|
||||
|
Cell Equalizer Current(A)
|
1~5A Max.
|
||||
|
Terminal
|
M6
|
||||
|
Storage temperature
|
0℃～30℃
|
||||
|
IP degree
|
IP20
|
||||
|
Storage duration
|
6 months at 25℃
|
||||
|
Safety standard
|
UN38.3,IEC62619,CE
|
||||
|
Display (Optional)
|
None or LCD display (Optional)
|
||||
|
Communication Port (Optional)
|
CAN/RS485/RS232 (Optional)
|
||||
|
PROTECTION
|
|||||
|
Protection
|
Overcharge protection、Overdischarge protection、Overcurrent protection、Shortcircuit protection、Overtemperature protection
|
||||
|
AMBIENT
|
|||||
|
working Temperature
|
-10℃～+50℃
|
||||
|
Humidity
|
0~95% ( no condensation)
|
||||
|
Sea Level(m)
|
≤1500
|
||||
|
DIMENSION
|
|||||
|
L×W×H (products size) mm
|
350*185*189
|
429*261*189
|
429*261*189
|
521*488*218
|
540*370*228
|
|
L×W×H (package size) mm
|
410*255*230
|
490*331*229
|
490*331*229
|
581*558*258
|
600*440*268
|
|
Weight(NW Kg)
|
17.0Kg
|
33.0Kg
|
33.0Kg
|
58.0Kg
|
58.0Kg
|
|
Weight(GW Kg)
|
17.5Kg
|
33.5Kg
|
33.5Kg
|
58.5Kg
|
58.5Kg
|
|
20FT QTY( UNIT)
|
1100 set
|
600 set
|
600 set
|
330 set
|
330 set
|
